1. Hart Tri Loop

The Rosemount 333 HART Tri-Loop allows you to convert a multivariable digital. And electrically isolated analog output channels for flexible configurations.

• Blanche Little
• 2 years ago
• Views:

Transcription

1 Product Data Sheet Rosemount 333 Rosemount 333 HART Tri-Loop HART-TO-ANALOG SIGNAL CONVERTER Convert a digital HART signal into three additional analog signals Easy to configure and install Accessory product for multivariable instruments Available as either High-alarm or Low-alarm device Contents Ordering Information page 3 Specifications page 3 Dimensional Drawings page 5

2 Rosemount 333 Product Data Sheet HART Tri-Loop HART-to-Analog Signal Converter Convert a digital HART signal into three analog signals Convert a multivariable digital HART signal into independent 4-20 ma analog process variables using the Rosemount 333 HART Tri-Loop. Apply in control or monitoring applications to obtain up to three additional analog outputs without additional process penetrations. Accessory product for multivariable instruments For use with the Rosemount 3051S MultiVariable, 3051S Advanced HART Diagnostics, and 3144P products. When used with the 3051S MultiVariable transmitter, the 333 HART Tri-Loop allows possible outputs of Differential, Absolute or Gage pressure, Process Temperature, Mass or Volumetric Flow, Energy Flow, Totalized Flow, and Sensor Module Temperature. When used with the 3051S Advanced HART Diagnostics, possible outputs include Pressure, Sensor Module Temperature, Scaled Variable, Deviation, and Mean. When used with the Rosemount 3144P, possible outputs include Sensor 1, Sensor 2, Differential and Transmitter Terminal Temperature. Easy to configure and install The 333 HART Tri-Loop is easy to configure and maintain using the 475 Field Communicator. AMS Device Manager provides easy PC-based user configuration. Installation is quick and easy with three DIN rail mount options and electrically isolated analog output channels for flexible grounding. Available as either High-alarm or Low-alarm device Tri-Loop alarm channels are factory configured. All channels alarm if the attached device indicates a sensor failure or transmitter malfunction. Figure 1. Example Tri-Loop Installation with Rosemount 3051S MultiVariable Transmitter HAZARDOUS AREA DIN Rail Mounted HART Tri-Loop Ch. 3 Ch. 2 Ch. 1 Burst Input to Tri-Loop Each Tri-Loop Channel receives power from Control Room Channel 1 must be powered for the Tri-Loop to operate Rosemount 3051S MultiVariable Transmitter RL 250 HART Burst Command 3/ Analog Output Intrinsically Safe Barrier Device receives power from Control Room for Primary Variable Loop Control Room NON HAZARDOUS AREA 2

3 Product Data Sheet Rosemount 333 Ordering Information Table 1. Rosemount 333 HART Tri-Loop The offering represents the most common options. The starred options ( ) should be selected for best delivery. The Expanded offering is subject to additional delivery lead time. Model Product Description 333 HART Tri-Loop Alarm Option U High Alarm D Low Alarm Configuration Option C2 Custom Configuration (Configuration Data Sheet must be completed) Typical Model Number: 333 U Specifications FUNCTIONAL SPECIFICATIONS Service Accessory product for use with the 3051S MultiVariable Transmitter, 3051S Advanced HART Diagnostics Transmitter, 3144P Temperature Transmitter, or any other HART device with a burst mode output. Output One, two, or three 4 20 ma user-selectable output signals. Device 3051S MultiVariable 3051S 3144P Output Options DP, AP, GP, PT, Mass or Volumetric, Energy Flow, Totalized Flow, and Sensor Module Temperature. Pressure, Sensor Module Temperature, Scaled Variable, Deviation, and Mean. Sensor 1, Sensor 2, Differential Temperature, or Transmitter Terminal Temperature. Power Supply External power supply required for each channel. Each channel operates on terminal voltage of Vdc. NOTE Channel 1 must be powered for Tri-Loop operation. Load Limitations Loop resistance is determined by the voltage level of the external power supply, as described below: Max. Loop Resistance = Power Supply Voltage Load (Ohms) Turn-on Time Analog signals will be within specifications five seconds after power is applied to Tri-Loop. Installation Locations Approved for FM ordinary locations, approved for CSA ordinary locations Temperature Limits Ambient 50 to 104 F (10 to 40 C) Operating Region Power Supply Voltage, Vdc Storage 40 to 158 F ( 40 to 70 C) 3

4 Rosemount 333 Product Data Sheet Humidity Limits 0 95% non-condensing relative humidity. Failure Mode Alarm If Tri-Loop diagnostics detect a Tri-Loop failure or the transmitter indicates a transmitter malfunction, the analog signal for all channels will be driven either below 3.75 ma or above ma to alert the user. The high or low alarm signal is determined by the Tri-Loop Model Number, see Alarm Configuration on page 4. PERFORMANCE SPECIFICATIONS (Performance specifications are for the HART Tri-Loop only.) Reference Accuracy ±0.045% of span Ambient Temperature Effect per 50 F (28 C) ±0.15% of span Stability ±0.1% of span for 12 months Analog Output Update Tri-Loop responds to every HART burst update (Typical transmitter burst update rate: 0.3 to 0.5 s.) Tri-Loop Response Time (after each burst update) Channel 1:120 ms; Channel 2:220 ms; Channel 3:320 ms Total Response Time Typical response time from sensor change to transmitter to Tri-Loop analog update: 0.7 to 1.0 seconds. Electromagnetic Compatibility (EMC) Meets all relevant requirements of EN :2006 ESD tested to 4 kv contact and 4 kv air EM field immunity from 80 MHz to 1 GHz tested to 3 V/m Limits of performance criterion A defined as < ± 0.1% of span PHYSICAL SPECIFICATIONS Electrical Connections Screw clamps. Accepts AWG solid or stranded wire. Dimensions in. ( ,5 mm) DIN Rail Mounting Options Asymmetrical 32 mm G rail, symmetrical mm top hat rail, or symmetrical mm top hat rail (see Tri-Loop Dimensions on page 5). Weight 0.27 lb (0,1 2 kg) Alarm Configuration Tri-Loops are configured with all channels to alarm in the same direction. Alarm direction is configured at the factory, and cannot be changed in the field. In addition, all channels alarm if the attached device indicates a sensor failure or transmitter malfunction. Tri-Loops are ordered according to the desired alarm direction. Configuration Unless otherwise specified with a C2 option, Tri-Loop is shipped as described in Table 2. Tri-Loop Label Each Tri-Loop is labeled with serial number, part number, and factory configuration. Custom Configuration If a Tri-Loop is ordered with a C2 option for custom configuration, the assigned variable, variable range, variable units, and channel status are assigned for all three channels. 333 HART Tri-Loop Configuration The 333 HART Tri-Loop can be fully configured using the 475 Field Communicator. AMS Device Manager software provides a PC-based user configuration. Table 2. Configuration Tri-Loop Channel Assigned Variable Variable Range Variable Units Channel Status Channel 1 Second inh 2 O at 68 F Disabled Channel 2 Third psi Disabled Channel 3 Fourth 40 to 400 Degree F Disabled 4

5 Product Data Sheet Rosemount 333 Figure 2. DIN Rail Mounting Options SYMMETRICAL 35 X 7.5 MM TOP HAT RAIL SYMMETRICAL 35 X 15 MM TOP HAT RAIL ASYMMETRICAL 32 MM G RAIL Dimensional Drawings Tri-Loop Dimensions 1.57 (40) 3.11 (79) 3.36 (86) NOTE Dimensions are in inches (millimeters) 5

6 Rosemount 333 Product Data Sheet Terms and Conditions of Sale can be found at The Emerson logo is a trade mark and service mark of Emerson Electric Co. Rosemount and the Rosemount logotype are registered trademarks of Rosemount Inc. Tri-Loop and MultiVariable are trademarks of Rosemount Inc. HART is a registered trademark of the HART Communication Foundation. All other marks are the property of their respective owners. Emerson Process Management Emerson Process Management Rosemount Measurement 8200 Market Boulevard Chanhassen MN USA Tel (USA) Tel (International) Fax Emerson Process Management Blegistrasse 23 P.O. Box 1046 CH 6341 Baar Switzerland Tel +41 (0) Fax +41 (0) Emerson FZE P.O. Box Jebel Ali Free Zone Dubai UAE Tel Fax Emerson Process Management Asia Pacific Pte Ltd 1 Pandan Crescent Singapore Tel Fax Service Support Hotline : Rev FA, 1/11

Rosemount 333 HART Tri-Loop
